Description

LOA 75 m
Beam 17,4 m
Draft 7 m
Bollard Pull : 193 tons

Dynamic Positioning of class : DP 2
Free Deck area about 525m² with a deck strength of 10 metric tonnes per square meter
Capable of supplies of 1.685m³ Fuel Oils, 641m³ FW, 430m³ Brine and 264m³ Dry bulk
Fire Fighting System of type FiFi 2 installed
1 Crane / Gear installed with a max lifting capacity of 5 tons
1 Crane / Gear installed with a max lifting capacity of 3 tons

Built in year 2012
Design is : AKER AH 08
Class : DNV
Flag : Bahamas
Gross Tonnage of 3.181 and Nett Tonnage of 1.129

Deadweight : 3.000 metric tonnes

Total 27 berths

Speed : 15 knots
Engines : 2 x Bergens / Bergen Engines AS B32:40V12P, 12.000 kw, 750 rpm, Propellers 1 Controllable Pitch (Port Side) + 1 Controllable Pitch (Starboard)
Auxiliaries Engines : 2 Scania 440 kw, Bowthruster + Sternthruster (2 Bow Tunnel thruster 880kw + 2 Stern Tunnel thruster 880kw)

Specifications

Engine(s)

2 x 12.000 kw, 750 rpm, Bergens / Bergen Engines AS B32:40V12P,
Propellers: 1 Controllable Pitch (Port Side) + 1 Controllable Pitch (Starboard)
